Our generators feature commercial-grade engines tested for 2,000 hours of continuous operation and extreme conditions. Their enclosures are designed to endure winds up to 181 MPH, ensuring resilience and durability.

Rated kW LP: 14 kW

Rated kW NG: 12 kW

Amps LP: 58 amps

Amps NG: 50 amps

Peak Motor Starting kVA @240 V: 33 kVa

Alternator Note: All information shown is for 1 Phase 60 Hz generator with the largest alternator option available.

Displacement:725 cm³ (44 cu. in.)

Horsepower: NG 20.5 HP, LP 23.6 HP

Enclosure Material: Aluminum

Sound Output During Weekly Exercise: 63 dB(A)

Sound output During Full-speed Operation: 67 dB(A)

Response Time: 10 seconds

Warranty: Premium five-year limited warranty

Country of Origin: US

Automatic Transfer Switch Included: Sold Separately

Remote Monitor Available: Included

Off Grid / Utility backup: Off GridUtility Backup

Weight: 440 lbs. (200 kg)

Alternator Type: 2-Pole, Rotating Field

Fuel Consumption on NG at 50% Load: 124 cfh

Fuel Consumption on LP at 50% Load?60 cfh

Controller: RDC2 Controller

Cylinder Arrangement: V-2

Dimensions: 47 in. x 26.2 in. x 32.2 in. (1193 mm x 666 mm x 817 mm)

Engine Manufacturer/Description: KOHLER

Engine Model: CH740

Engin/Alternator RPM: 3600

Fuel Type: Natural Gas | LPG

Frequency: 60 Hz

Phase: Single Phase Three Phase

Voltage @60 Hzs: 120/240

Digital Voltage Regulation: ±1.0%
