Our generators feature commercial-grade engines tested for 2,000 hours of continuous operation and extreme conditions. Their enclosures are designed to endure winds up to 181 MPH, ensuring resilience and durability.

Rated kW LP: 12 kW

Rated kW NG: 10.4 kW

Amps LP: 50 amps

Amps NG: 43 amps

Peak Motor Starting kVA @240 V: 32 kVa

Alternator Note: All information shown is for 1 Phase 60 Hz generator with the largest alternator option available.

Displacement: 0.725 L (44 cu. in.)

Horsepower: NG 20.5 HP, LP 23.6 HP

Enclosure Material: Steel

Sound Output During Weekly Exercise: 65 dB(A)

Sound output During Full-speed Operation: 65 dB(A)

Response Time: 10 seconds

Country of Origin: US

Automatic Transfer Switch Included: Included

Off Grid / Utility backup: Off GridUtility Backup

Weight: 400 lbs. (182 kg)

Alternator Type: 2-Pole, Rotating Field

Fuel Consumption on NG at 50% Load: 124 cfh

Fuel Consumption on LP at 50% Load: 60 cfh

Controller: ADC-RES Controller

Cylinder Arrangement: V-2

Dimensions: 1123 mm x 726 mm x 804 mm (44.2 in. x 28.6 in. x 31.6 in.)

Engine Manufacturer/Description: KOHLER

Engine Model: CH740

Engin/Alternator RPM: 3600

Fuel Type: Natural Gas | LPG

Frequency: 50 Hz | 60 Hz

Phase: Single Phase

Voltage @60 Hzs: 120/240

Digital Voltage Regulation: ±1.5%

Built in Mounting pad: Yes
